Сабвуфер DLS MCW12

Woofer size    12" (30 cm)
Outer diameter of woofer    310 mm (12")
Mounting depth    130mm (5,12")
Mounting hole    280 mm (11")
X-max    +- 9 mm (0,35")
Frequency range    20 Hz - 1 kHz
Impedance    4 ohm
Sensitivity    87,75 dB
Power handling capacity    250 W
Max power handling capacity    500 W
Peak power    700 W
T/S parameters
single V/C
Fs     33,5     Hz      Re     3,0     Ohm      Qms     6,16
Vas     57     liter      Vas     2,0     Cuft      Qes     0,57
Qts     0,52          Sd     491     cm²      BL     12,13
Magnet size    120 mm (4,72")
