Усилитель 4-канальный DLS CCi4
Number of channels 4
Amplifier class AB
Output power in 2 ohm 4 x 70 Watt
Output power in 4 ohm 4 x 50 Watt
Mono bridge mode 4 ohm 2 x 140 Watt
Damping factor >250
S/N ratio, A-weighted >110 dB
Frequency range 10 Hz - 55 kHz
Input sensitivity 1 - 4 Volt
Input impedance 6 kohm
Input impedance, high level 45 ohm
High level input with auto start Yes
Remote bass level control No
Low level output No
Remote phase shift control No
Filters channel A & B HP 50 - 500 Hz, LP 50 - 500 Hz
Filters channel C & D HP 50 - 500 Hz, LP 50 - 500 Hz
Power consumption (idle) 0,5 A
Power consumption (max) 40 A
Fuses use external fuse 40A
Dimension (W x D x H) 129 x 320 x 54 mm (5,1" x 12,6" x 2,1")
Weight 1,8 kg
Amplifier class AB
Output power in 2 ohm 4 x 70 Watt
Output power in 4 ohm 4 x 50 Watt
Mono bridge mode 4 ohm 2 x 140 Watt
Damping factor >250
S/N ratio, A-weighted >110 dB
Frequency range 10 Hz - 55 kHz
Input sensitivity 1 - 4 Volt
Input impedance 6 kohm
Input impedance, high level 45 ohm
High level input with auto start Yes
Remote bass level control No
Low level output No
Remote phase shift control No
Filters channel A & B HP 50 - 500 Hz, LP 50 - 500 Hz
Filters channel C & D HP 50 - 500 Hz, LP 50 - 500 Hz
Power consumption (idle) 0,5 A
Power consumption (max) 40 A
Fuses use external fuse 40A
Dimension (W x D x H) 129 x 320 x 54 mm (5,1" x 12,6" x 2,1")
Weight 1,8 kg
